Cosmic rays are energetic particles originating from space that impinge on Earth's atmosphere. Almost 90% of all the incoming cosmic ray particles are protons, about 9% are helium nuclei (alpha particles) and about 1% are electrons (beta minus particles). The term "ray" is a misnomer, as cosmic particles arrive individually, not in the form of a ray or beam of particles.
The variety of particle energies reflects the wide variety of sources. The origins of these particles range from energetic processes on the Sun all the way to as yet unknown events in the farthest reaches of the visible universe. Cosmic rays can have energies of over 1020 eV, far higher than the 1012 to 1013 eV that man-made particle accelerators can produce. (See Ultra-high-energy cosmic rays for a description of the detection of a single particle with an energy of about 50 J, the same as a well-hit tennis ball at 42 m/s [about 94 mph].) There has been interest in investigating cosmic rays of even greater energies.
Composition
Cosmic rays may broadly be divided into two categories, primary and secondary.
The cosmic rays that arise in extrasolar astrophysical sources are primary cosmic rays; these primary cosmic rays can interact with interstellar matter to create secondary cosmic rays. The sun also emits low energy cosmic rays associated with solar flares. The exact composition of primary cosmic rays, outside the Earth's atmosphere, is dependent on which part of the energy spectrum is observed. However, in general, almost 90% of all the incoming cosmic rays are protons, about 9% are helium nuclei (alpha particles) and about 1% are electrons. The remaining fraction is made up of the other heavier nuclei which are abundant end products of star’s nuclear synthesis. Secondary cosmic rays consist of the other nuclei which are not abundant nuclear synthesis end products, or products of the Big Bang, primarily lithium, beryllium and boron. These light nuclei appear in cosmic rays in much greater abundance (about 1:100 particles) than in solar atmospheres, where their abundance is about 10-7 that of helium.
This abundance difference is a result of the way secondary cosmic rays are formed. When the heavy nuclei components of primary cosmic rays, namely the carbon and oxygen nuclei, collide with interstellar matter, they break up into lighter nuclei (in a process termed cosmic ray spallation), into lithium, beryllium and boron. It is found that the energy spectra of Li, Be and B falls off somewhat steeper than that of carbon or oxygen, indicating that less cosmic ray spallation occurs for the higher energy nuclei presumably due to their escape from the galactic magnetic field. Spallation is also responsible for the abundances of Sc, Ti, V and Mn elements in cosmic rays, which are produced by collisions of Fe and Ni nuclei with interstellar matter; see Environmental radioactivity#Naturals.
In the past, it was believed that the cosmic ray flux has remained fairly constant over time. Recent research has, however, produced evidence for 1.5 to 2-fold millennium-timescale changes in the cosmic ray flux in the past forty thousand years.
Modulation
The flux (flow rate) of cosmic rays incident on the Earth’s upper atmosphere is modulated (varied) by two processes; the sun’s solar wind and the Earth's magnetic field. Solar wind is expanding magnetized plasma generated by the sun, which has the effect of decelerating the incoming particles as well as partially excluding some of the particles with energies below about 1 GeV. The amount of solar wind is not constant due to changes in solar activity, for instance over its regular eleven-year cycle. Hence the level of modulation varies in autocorrelation with solar activity. Also the Earth's magnetic field deflects some of the cosmic rays, which is confirmed by the fact that the intensity of cosmic radiation is dependent on latitude, longitude and azimuth. The cosmic flux varies from eastern and western directions due to the polarity of the Earth’s geomagnetic field and the positive charge dominance in primary cosmic rays; this is termed the east-west effect. The cosmic ray intensity at the equator is lower than at the poles as the geomagnetic cutoff value is greatest at the equator. This can be understood by the fact that charged particle tend to move in the direction of field lines and not across them. This is the reason the Aurorae occur at the poles, since the field lines curve down towards the Earth’s surface there. Finally, the longitude dependence arises from the fact that the geomagnetic dipole axis is not parallel to the Earth’s rotation axis.
This modulation which describes the change in the interstellar intensities of cosmic rays as they propagate in the heliosphere is highly energy and spatial dependent, and it is described by the Parker's Transport Equation in the heliosphere. At large radial distances, far from the Sun ~ 94 AU, there exists the region where the solar wind undergoes a transition from supersonic to subsonic speeds called the solar wind termination shock. The region between the termination shock and the heliospause (the boundary marking the end of the heliosphere) is called the heliosheath. This region acts as a barrier to cosmic rays and it decreases their intensities at lower energies by about 90% indicating that it is not only the Earth's magnetic field that protect us from cosmic ray bombardment.
From modelling point of view, there is a challenge in determining the Local Interstellar spectra (LIS) due to large adiabatic energy changes these particles experience owing to the diverging solar wind in the heliosphere. However, significant progress has been made in the field of cosmic ray studies with the development of an improved state-of-the-art 2D numerical model that includes the simulation of the solar wind termination shock, drifts and the heliosheath coupled with fresh descriptions of the diffusion tensor, see Langner et al. (2004). But challenges also exist because the structure of the solar wind and the turbulent magnetic field in the heliosheath is not well understood indicating the heliosheath as the region unknown beyond. With lack of knowledge of the diffusion coefficient perpendicular to the magnetic field our knowledge of the heliosphere and from the modelling point of view is far from complete. There exist promising theories like ab initio approaches, but the drawback is that such theories produce poor compatibility with observations (Minnie, 2006) indicating their failure in describing the mechanisms influencing the cosmic rays in the heliosphere.
Detection
The nuclei that make up cosmic rays are able to travel from their distant sources to the Earth because of the low density of matter in space. Nuclei interact strongly with other matter, so when the cosmic rays approach Earth they begin to collide with the nuclei of atmospheric gases. These collisions, in a process known as a shower, result in the production of many pions and kaons, unstable mesons which quickly decay into muons. Because muons do not interact strongly with the atmosphere and because of the relativistic effect of time dilation many of these muons are able to reach the surface of the Earth. Muons are ionizing radiation, and may easily be detected by many types of particle detectors such as bubble chambers or scintillation detectors. If several muons are observed by separated detectors at the same instant it is clear that they must have been produced in the same shower event.
Detection by particle track-etch technique
Cosmic rays can also be detected directly when they pass through particle detectors flown aboard satellites or in high altitude balloons. In a pioneering technique developed by P. Buford Price et al., sheets of clear plastic such as 1/4 mil Lexan polycarbonate can be stacked together and exposed directly to cosmic rays in space or high altitude. When returned to the laboratory, the plastic sheets are "etched" [literally, slowly dissolved] in warm caustic sodium hydroxide solution, which slowly removes the surface material at a slow, known rate. Wherever a bare cosmic ray nucleus passes through the detector, the nuclear charge causes chemical bond breaking in the plastic. The slower the particle, the more extensive is the bond-breaking along the path; and the higher the charge [the higher the Z], the more extensive is the bond-breaking along the path. The caustic sodium hydroxide dissolves at a faster rate along the path of the damage, but thereafter dissolves at the slower base-rate along the surface of the minute hole that was drilled. The net result is a conical shaped pit in the plastic; typically with two pits per sheet [one originating from each side of the plastic]. The etch pits can be measured under a high power microscope [typically 1600X oil-immersion], and the etch rate plotted as a function of the depth in the stack of plastic. At the top of the stack, the ionization damage is less due to the higher speed. As the speed decreases due to deceleration in the stack, the ionization damage increases along the path. This generates a unique curve for each atomic nucleus of Z from 1 to 92, allowing identification of both the charge and energy [speed] of the particle that traverses the stack. This technique has been used with great success for detecting not only cosmic rays, but fission product nuclei for neutron detectors.
Interaction with the Earth's atmosphere
When cosmic ray particles enter the Earth's atmosphere they collide with molecules, mainly oxygen and nitrogen, to produce a cascade of lighter particles, a so-called air shower. The general idea is shown in the figure which shows a cosmic ray shower produced by a high energy proton of cosmic ray origin striking an atmospheric molecule.
This image is a simplified picture of an air shower: in reality, the number of particles created in an air shower event can reach in the billions, depending on the energy and chemical environment (i.e. atmospheric) of the primary particle. All of the produced particles stay within about one degree of the primary particle's path. Typical particles produced in such collisions are charged mesons (e.g. positive and negative pions and kaons); one common collision is:
Cosmic rays are also responsible for the continuous production of a number of unstable isotopes in the Earth’s atmosphere, such as carbon-14, via the reaction:
Cosmic rays kept the level of carbon-14 in the atmosphere roughly constant (70 tons) for at least the past 100,000 years, until the beginning of aboveground nuclear weapons testing in the early 1950s. This is an important fact used in radiocarbon dating which is used in archaeology.
Research and experiments
There are a number of cosmic ray research initiatives. These include, but are not limited to:
- Ground Experiment
- Satellite Experiment
- Balloon-borne Experiment
History
After the discovery of radioactivity by Henri Becquerel in 1896, it was generally believed that atmospheric electricity (ionization of the air) was caused only by radiation from radioactive elements in the ground or the radioactive gases (isotopes of radon) they produce. Measurements of ionization rates at increasing heights above the ground during the decade from 1900 to 1910 showed a decrease that could be explained as due to absorption of the ionizing radiation by the intervening air.
In 1910 Theodor Wulf developed an electrometer (a device to measure the rate of ion production inside a hermetically sealed container) and used it to show higher levels of radiation at the top of the Eiffel Tower than at its base, but his paper in published in Physikalische Zeitschrift was not widely accepted. In 1912 Domenico Pacini observed simultaneous variations of the rate of ionization over a lake, and over the sea. Pacini concluded that a certain part of the ionization must be due to sources other than the radioactivity of the Earth or the air. Then, in 1912, Victor Hess built three enhanced-accuracy Wulf electrometers and carried them aloft to an altitude of 5300 meters in a free balloon flight. He found the ionization rate increased approximately fourfold over the rate at ground level. Hess also ruled out the sun as the radiation's source by making a balloon ascent during a near-total eclipse. With the moon blocking much of the sun's visible radiation, Hess still measured rising radiation at rising altitudes. He concluded "The results of my observation are best explained by the assumption that a radiation of very great penetrating power enters our atmosphere from above." In 1913–1914, Werner Kolhörster confirmed Victor Hess' earlier results by measuring the increased ionization rate at an altitude of 9 km.
Hess received the Nobel Prize in Physics in 1936 for his discovery.
The term "cosmic rays" was coined by Robert Millikan who proved they were extraterrestrial in origin, and not produced by atmospheric electricity as Hess had thought. Millikan believed that cosmic rays were high-energy photons with some secondary electrons produced by Compton scattering of gamma rays. Compton himself held the (correct) belief that cosmic rays were primarily charged particles. During the decade from 1927 to 1937, a wide variety of experimental investigations demonstrated that the primary cosmic rays are mostly positively charged particles, and the secondary radiation observed at ground level is composed primarily of a "soft component" of electrons and photons and a "hard component" of penetrating particles, muons. The muon was initially believed to be the unstable particle predicted by Hideki Yukawa in 1935 in his theory of the nuclear force. Experiments proved that the muon decays with a mean life of 2.2 microseconds into an electron and two neutrinos, but that it does not interact strongly with nuclei, so it could not be the Yukawa particle. The mystery was solved by the discovery in 1947 of the pion, which is produced directly in high-energy nuclear interactions. It decays into a muon and one neutrino with a mean life of 0.0026 microseconds. The pion?muon?electron decay sequence was observed directly in a microscopic examination of particle tracks in a special kind of photographic plate called a nuclear emulsion that had been exposed to cosmic rays at a high-altitude mountain station. In 1948, observations with nuclear emulsions carried by balloons to near the top of the atmosphere by Gottlieb and Van Allen showed that the primary cosmic particles are mostly protons with some helium nuclei (alpha particles) and a small fraction heavier nuclei.
In 1934 Bruno Rossi reported an observation of near-simultaneous discharges of two Geiger counters widely separated in a horizontal plane during a test of equipment he was using in a measurement of the so-called east-west effect. In his report on the experiment, Rossi wrote "...it seems that once in a while the recording equipment is struck by very extensive showers of particles, which causes coincidences between the counters, even placed at large distances from one another. Unfortunately, he did not have the time to study this phenomenon more closely." In 1937 Pierre Auger, unaware of Rossi's earlier report, detected the same phenomenon and investigated it in some detail. He concluded that extensive particle showers are generated by high-energy primary cosmic-ray particles that interact with air nuclei high in the atmosphere, initiating a cascade of secondary interactions that ultimately yield a shower of electrons, photons, and muons that reach ground level.
Homi J. Bhabha derived an expression for the probability of scattering positrons by electrons, a process now known as Bhabha scattering. His classic paper, jointly with Warren Heitler, published in 1937 described how primary cosmic rays from space interact with the upper atmosphere to produce particles observed at the ground level. Bhabha and Heitler explained the cosmic ray shower formation by the cascade production of gamma rays and positive and negative electron pairs. In 1938 Bhabha concluded that observations of the properties of such particles would lead to the straightforward experimental verification of Albert Einstein's theory of relativity.
Measurements of the energy and arrival directions of the ultra-high-energy primary cosmic rays by the techniques of "density sampling" and "fast timing" of extensive air showers were first carried out in 1954 by members of the Rossi Cosmic Ray Group at the Massachusetts Institute of Technology. The experiment employed eleven scintillation detectors arranged within a circle 460 meters in diameter on the grounds of the Agassiz Station of the Harvard College Observatory. From that work, and from many other experiments carried out all over the world, the energy spectrum of the primary cosmic rays is now known to extend beyond 1020 eV (past the GZK cutoff, beyond which very few cosmic rays should be observed). A huge air shower experiment called the Auger Project is currently operated at a site on the pampas of Argentina by an international consortium of physicists. Their aim is to explore the properties and arrival directions of the very highest energy primary cosmic rays. The results are expected to have important implications for particle physics and cosmology. In November, 2007 preliminary results were announced showing direction of origination of the 27 highest energy events were strongly correlated with the locations of active galactic nuclei [AGN], where bare protons are believed accelerated by strong magnetic fields associated with the large black holes at the AGN centers to energies of 1020 eV and higher.
Three varieties of neutrino are produced when the unstable particles produced in cosmic ray showers decay. Since neutrinos interact only weakly with matter most of them simply pass through the Earth and exit the other side. They very occasionally interact, however, and these atmospheric neutrinos have been detected by several deep underground experiments. The Super-Kamiokande in Japan provided the first convincing evidence for neutrino oscillation in which one flavour of neutrino changes into another. The evidence was found in a difference in the ratio of electron neutrinos to muon neutrinos depending on the distance they have traveled through the air and earth.
Effects
Role in ambient radiation
Cosmic rays constitute a fraction of the annual radiation exposure of human beings on earth. For example, the average radiation exposure in Australia is 0.3 mSv due to cosmic rays, out of a total of 2.3 mSv.
Effect on electronics
Cosmic rays have sufficient energy to alter the states of elements in electronic integrated circuits, causing transient errors to occur, such as corrupted data in memory, or incorrect behavior of a CPU. This has been a problem in high-altitude electronics, such as in satellites, but as transistors become smaller it is becoming an increasing concern in ground-level equipment as well.
To alleviate this problem, Intel has proposed a cosmic ray detector which could be integrated into future high-density microprocessors, allowing the processor to repeat the last command following a cosmic ray event.
Significance to space travel
Galactic cosmic rays are one of the most important barriers standing in the way of plans for interplanetary travel by crewed spacecraft. See Health threat from cosmic rays.
Role in lightning
Cosmic rays have been implicated in the triggering of electrical breakdown in lightning. It has been proposed that essentially all lightning is triggered through a relativistic process, "runaway breakdown", seeded by cosmic ray secondaries. Subsequent development of the lightning discharge then occurs through "conventional breakdown" mechanisms.
Role in climate change
A role of cosmic rays directly or via solar-induced modulations in recent climate change as suggested 1995 by Henrik Svensmark is still disputed. The 2007 IPCC reports mention enhanced empirical results for a stronger evidence for solar forcing of climate change, the purported attribution to cosmic rays remaining ambiguous and being less probable.
Suggested Mechanisms
Henrik Svensmark et al. have argued that solar variations modulate the cosmic ray signal seen at the earth and that this would affect cloud formation and hence climate. Cosmic rays have been experimentally determined to be able to produce ultra-small aerosol particles, orders of magnitude smaller than cloud condensation nuclei (CCN).
According to a report about an ongoing CERN research project to detect any Cosmic ray forcing is challenging since on wide spread time scales changes in the Sun’s magnetic activity, Earth’s magnetic field, and the galactic environment have to be take into account. Empirically, increased GCR flux seem to be associated with a cooler climate, a southerly shift of the ITCZ (Inter Tropical Convergence Zone) and a weakening of monsoon rainfalls and vice versa. Claims have been made of identification of GCR climate signals in atmospheric parameters such as high latitude precipitation (Todd & Kniveton), and Svensmark's annual cloud cover variations, which were said to be correlated to GCR variation. Various proposals have been made for the mechanism by which cosmic rays might affect clouds, including ion mediated nucleation, and indirect effects on current flow density in the global electric circuit (see Tinsley 2000, and F. Yu 1999). Other studies refer to the formation of relatively highly charged aerosols and cloud droplets at cloud boundaries, with an indirect effect on ice particle formation and altering aerosol interaction with cloud droplets.
Geochemical and astrophysical evidence
Nir Shaviv has argued that climate signals on geological time scales are attributable to changing positions of the galactic spiral arms of the Milky Way, and that cosmic ray flux variability is the dominant climate driver over these time periods. Nir Shaviv and Jan Veizer in 2003 argue, that in contrast to a carbon based scenario, the model and proxy based estimates of atmospheric CO2 levels especially for the early Phanerozoic (see diagrams) do not show correlation with the paleoclimate picture that emerged from geological criteria, while cosmic rays flux would do.
The 2007 IPCC reports however strongly attribute a major role of anthropogenic carbon dioxide in the ongoing global warming, but as "different climate changes in the past had different causes" a driving role of Carbon dioxide in the geological past is neither focus of the IPCC nor purported. Similarly, according a BBC report a 2008 Lancaster University study produced "further compelling evidence showing that modern-day climate change is not caused by changes in the Sun's activity".
A comprehensive study of different research institutes was published 2007 by Scherer et al. in Space Science Reviews 2007. The study combines geochemical evidence both on temperature, cosmic rays influence and as well astrophysical deliberations suggesting a major role in climate variability over different geological time scales. Proxy data of CRF influence comprise among others isotopic evidence in sediments on earth and as well changes in (iron) meteorites.
Lacking evidence of an accepted mechanism relating cosmic ray and climate e.g. via cloud cover variation and the challenges to obtain correct historical data on cosmic ray flux at various ranges of energies still lead to controversies
See-also Global warming#Solar variation.
Cosmic rays and fiction
In fiction, cosmic rays have been used as a catchall, mostly in comics (notably the Marvel Comics group the Fantastic Four), as a source for mutation and therefore the powers gained by being bombarded with them.
In the book Atlas Shrugged by author Ayn Rand, Dr. Robert Stadler's research of cosmic rays is said to have contributed to "Project X", a weapon of mass destruction.
