Root nodules occur on the roots of plants (primarily
FabaceaeThe Fabaceae or Leguminosae, commonly known as the legume, pea, or bean family, is a large and economically important family of flowering plants. The group is the third largest land plant family, behind only the Orchidaceae and Asteraceae, with 730 genera and over 19,400 species...
) that associate with symbiotic
nitrogen-fixingNitrogen fixation is the natural process, either biological or abiotic, by which nitrogen in the atmosphere is converted into ammonia . This process is essential for life because fixed nitrogen is required to biosynthesize the basic building blocks of life, e.g., nucleotides for DNA and RNA and...
bacteria. Under
nitrogenNitrogen is a chemical element that has the symbol N, atomic number of 7 and atomic mass 14.00674 u. Elemental nitrogen is a colorless, odorless, tasteless, and mostly inert diatomic gas at standard conditions, constituting 78.08% by volume of Earth's atmosphere...
-limiting conditions, capable plants form a symbiotic relationship with a host-specific strain of bacteria known as
rhizobiaRhizobia are soil bacteria that fix nitrogen after becoming established inside root nodules of legumes . Rhizobia require a plant host; they cannot independently fix nitrogen...
. This process has evolved multiple times within the Fabaceae, as well as in other species found within the Rosid clade.
Within legume nodules, nitrogen gas from the atmosphere is converted into
ammoniaAmmonia is a compound of nitrogen and hydrogen with the formula . It is a colourless gas with a characteristic pungent odour. Ammonia contributes significantly to the nutritional needs of terrestrial organisms by serving as a precursor to food and fertilizers. Ammonia, either directly or...
, which is then assimilated into amino acids (the building blocks of proteins), nucleotides (the building blocks of DNA and RNA as well as the important energy molecule ATP), and other cellular constituents such as
vitaminA vitamin is an organic compound required as a nutrient in tiny amounts by an organism. In other words, an organic chemical compound is called a vitamin when it cannot be synthesized in sufficient quantities by an organism, and must be obtained from the diet. Thus, the term is conditional both on...
s, flavones, and hormones. Their ability to
fixNitrogen fixation is the natural process, either biological or abiotic, by which nitrogen in the atmosphere is converted into ammonia . This process is essential for life because fixed nitrogen is required to biosynthesize the basic building blocks of life, e.g., nucleotides for DNA and RNA and...
gaseous nitrogen makes legumes an ideal agricultural organism as their requirement for nitrogen fertilizer is reduced. Indeed high nitrogen content blocks nodule development as there is no benefit for the plant of forming the symbiosis. The energy for splitting the nitrogen gas in the nodule comes from sugar that is translocated from the leaf (a product of photosynthesis). Malate as a breakdown product of sucrose is the direct carbon source for the bacteroid. Nitrogen fixation in the nodule is very oxygen sensitive. Legume nodules harbor an iron containing protein called leghaemoglobin, closely related to animal myoglobin, to facilitate the conversion of nitrogen gas to ammonia.
Classification
Two main types of nodule have been described: determinate and indeterminate.
Determinate nodules are found on tropical (sub)legumes, such as those of the genera
GlycineGlycine is a genus in the bean family Fabaceae. The best known species is the soybean . While the majority of the species are found only in Australia, the soybean's native range is in East Asia. A few species extend from Australia to East Asia Glycine is a genus in the bean family Fabaceae. The...
(soybean),
PhaseolusPhaseolus is a genus in the family Fabaceae of about fifty plant species, all native to the Americas.At least four of the species have been domesticated since pre-Columbian times for their beans. Most prominent among these is the common bean, P...
(common bean),
LotusLotus is a genus that includes bird's-foot trefoils and deervetches and contains many dozens of species distributed world-wide. Depending on the taxonomic authority, roughly between 70 and 150 are accepted. Lotus is a genus of legume and its members are adapted to a wide range of habitats, from...
, and
VignaThe genus Vigna is in the plant family Fabaceae. The genus is named after Domenico Vigna, an Italian botanist of the 17th century. They include some well-known and other less well-known beans formerly — and sometimes still, especially in non-scholarly sources — included in the genus Phaseolus...
. Determinate nodules lose meristematic activity shortly after initiation, thus growth is due to cell expansion resulting in mature nodules which are spherical in shape.
Indeterminate nodules are found on temperate
legumes like
PisumPisum is a genus of the family Fabaceae, native to southwest Asia and northeast Africa. It contains one to five species, depending on taxonomic interpretation; the International Legume Database accepts three species, one with two subspecies :...
(pea),
MedicagoMedicago is a genus of flowering plants, commonly known as medick or burclover. The name is based on Latin medica 'alfalfa, lucerne,' from 'Median .'...
(alfalfa),
Trifolium (clover), and
ViciaVicia is a genus of about 140 species of flowering plants commonly known as vetches. It is in the legume family . Member species are native to Europe, North America, South America, Asia and Africa. Some other genera of their subfamily Faboideae also have names containing "vetch", for example the...
(vetch). They earned the moniker "indeterminate" because they maintain an active apical
meristemA meristem is the tissue in most plants consisting of undifferentiated cells , found in zones of the plant where growth can take place....
that produces new cells for growth over the life of the nodule. This results in the nodule having a generally cylindrical shape. Because they are actively growing, indeterminate nodules manifest zones which demarcate different stages of development/symbiosis:
- Zone I—the active meristem. This is where new nodule tissue is formed which will later differentiate into the other zones of the nodule.
- Zone II—the infection zone. This zone is permeated with infection threads full of bacteria. The plant cells are larger than in the previous zone and cell division is halted.
- Interzone II–III—Here the bacteria have entered the plant cells, which contain amyloplast
Amyloplasts are non-pigmented organelles found in some plant cells. They are responsible for the synthesis and storage of starch granules, through the polymerization of glucose. Amyloplasts also convert this starch back into sugar when the plant needs energy...
s. They elongate and begin terminally differentiating into symbiotic, nitrogen-fixing bacteroids.
- Zone III—the nitrogen fixation zone. Each cell in this zone contains a large, central vacuole
A vacuole is a membrane-bound organelle which is present in all plant and fungal cells and some protist, animal and bacterial cells. Vacuoles are essentially enclosed compartments which are filled with water containing inorganic and organic molecules including enzymes in solution, though in certain...
and the cytoplasm is filled with fully differentiated bacteroids which are actively fixing nitrogenNitrogen fixation is the natural process, either biological or abiotic, by which nitrogen in the atmosphere is converted into ammonia . This process is essential for life because fixed nitrogen is required to biosynthesize the basic building blocks of life, e.g., nucleotides for DNA and RNA and...
. The plant provides these cells with leghemoglobinLeghemoglobin is a nitrogen or oxygen carrier, because naturally occurring oxygen and nitrogen interact similarly with this protein; and a hemoprotein found in the nitrogen-fixing root nodules of leguminous plants. But nitrogen is necessary for the cycle to occur...
, resulting in a distinct pink color.
- Zone IV—the senescent zone. Here plant cells and their bacteroid contents are being degraded. The breakdown of the heme component of leghemoglobin results in a visible greening at the base of the nodule.
Nodulation
Legumes release compounds called
flavonoidFlavonoids , are a class of plant secondary metabolites....
s from their roots, which trigger the production of
nod factorNodulation factors are signaling molecules produced by bacteria known as rhizobia during the initiation of nodules on the root of legumes. A symbiosis is formed when legumes take up the bacteria...
s by the bacteria. When the nod factor is sensed by the root, a number of biochemical and morphological changes happen:
cell divisionCell division is the process by which a parent cell divides into two or more daughter cells . Cell division is usually a small segment of a larger cell cycle. This type of cell division in eukaryotes is known as mitosis, and leaves the daughter cell capable of dividing again. The corresponding sort...
is triggered in the root to create the nodule, and the
root hairA root hair, the rhizoid of a vascular plant, is a tubular outgrowth of a trichoblast, a hair-forming cell on the epidermis of a plant root. That is, root hairs are lateral extensions of a single cell and only rarely branched, thus invisible to the naked eye. They are found only in the region of...
growth is redirected to wind around the bacteria multiple times until it fully encapsulates 1 or more bacteria. The bacteria encapsulated divide multiple times, forming a microcolony. From this microcolony, the bacteria enter the developing nodule through a structure called an infection thread, which grows through the root hair into the basal part of the
epidermisThe epidermis is a single-layered group of cells that covers plants' leaves, flowers, roots and stems. It forms a boundary between the plant and the external environment. The epidermis serves several functions, it protects against water loss, regulates gas exchange, secretes metabolic compounds,...
cell, and onwards into the
root cortexIn botany, the cortex is the outer layer of the stem or root of a plant, bounded on the outside by the epidermis and on the inside by the endodermis. It is composed mostly of undifferentiated cells, usually large thin-walled parenchyma cells of the ground tissue system. The outer cortical cells...
; they are then surrounded by a plant-derived membrane and differentiate into bacteroids that
fix nitrogenNitrogen fixation is the natural process, either biological or abiotic, by which nitrogen in the atmosphere is converted into ammonia . This process is essential for life because fixed nitrogen is required to biosynthesize the basic building blocks of life, e.g., nucleotides for DNA and RNA and...
.
Nodulation is controlled by a variety of processes, both external (heat, acidic soils, drought, nitrate) and internal (autoregulation of nodulation, ethylene). Autoregulation of nodulation controls nodule numbers per plant through a systemic process involving the leaf. Leaf tissue senses the early nodulation events in the root through an unknown chemical signal, then restricts further nodule development in newly developing root tissue. The Leucine rich repeat (LRR) receptor kinases (NARK in soybean (
Glycine max); HAR1 in
Lotus japonicusLotus japonicus is a wild legume that belongs to family Fabaceae. Members of this family are very diverse, constituting about 20,000 species. They are of significant agricultural and biological importance as many of the legume species are rich sources of protein and oil and can also fix atmospheric...
, SUNN in
Medicago truncatulaMedicago truncatula is a small legume native to the Mediterranean region that is used in genomic research. It is a low-growing, clover-like plant 10–60 cm tall with trifoliate leaves. Each leaflet is rounded, 1–2 cm long, often with a dark spot in the center...
) are essential for autoregulation of nodulation (AON). Mutation leading to loss of function in these AON receptor kinases leads to supernodulation or hypernodulation. Often root growth abnormalities accompany the loss of AON receptor kinase activity, suggesting that nodule growth and root development are functionally linked. I. Investigations into the mechanisms of nodule formation showed that the
ENOD40enod40, also known as early nodulin 40, is a gene found in flowering plants. The gene has characteristics of both protein and Non-coding RNA genes...
gene, coding for a 12–13 amino acid protein [41], is up-regulated during nodule formation [3].
Connection to root structure
Root nodules apparently have evolved three times within the
FabaceaeThe Fabaceae or Leguminosae, commonly known as the legume, pea, or bean family, is a large and economically important family of flowering plants. The group is the third largest land plant family, behind only the Orchidaceae and Asteraceae, with 730 genera and over 19,400 species...
but are rare outside that family. The propensity of these plants to develop root nodules seems to relate to their root structure. In particular, a tendency to develop lateral roots in response to
abscisic acidAbscisic acid , also known as abscisin II and dormin, is a plant hormone. ABA functions in many plant developmental processes, including bud dormancy. It is degraded by the enzyme -abscisic acid 8'-hydroxylase.-Function:...
may enable the later evolution of root nodules.
In other species
Root nodules that occur on non-legume genera like
Parasponia in association with Rhizobium bacteria, and those that arise from symbiotic interactions with
ActinobacteriaActinobacteria are a group of Gram-positive bacteria with high guanine and cytosine content. They can be terrestrial or aquatic. Actinobacteria is one of the dominant phyla of the bacteria....
FrankiaFrankia is a genus of nitrogen fixing, filamentous bacteria that live in symbiosis with actinorhizal plants, similar to the Rhizobia bacteria that are found in the root nodules of legumes in the Fabaceae family. Bacteria of this genus also form root nodules.The genus Frankia was originally named by...
in some plant genera such as
AlnusAlder is the common name of a genus of flowering plants belonging to the birch family . The genus comprises about 30 species of monoecious trees and shrubs, few reaching large size, distributed throughout the North Temperate Zone and in the Americas along the Andes southwards to...
, vary significantly from those formed in the legume-rhizobia symbiosis. In these symbioses the bacteria are never released from the infection thread.
Frankia nodulates approximately two hundred species in the following orders (families in parentheses):
CucurbitalesThe Cucurbitales are an order of flowering plants, included in the rosid group of dicotyledons. This order mostly belongs to tropical areas, with limited presence in subtropic and temperate regions. The order includes shrubs and trees, together with many herbs and climbers...
(Coriariaceae and
DatiscaceaeDatiscaceae are a family of Dicotyledonous plants, containing two species of the genus Datisca. Two other genera, Octomeles and Tetrameles are now classified in the Tetramelaceae family....
),
FagalesThe Fagales are an order of flowering plants, including some of the best known trees. The order name is derived from genus Fagus, Beeches. They belong among the rosid group of dicotyledons...
(
BetulaceaeBetulaceae, or the Birch Family, includes six genera of deciduous nut-bearing trees and shrubs, including the birches, alders, hazels, hornbeams and hop-hornbeams, numbering about 130 species...
,
CasuarinaceaeCasuarinaceae is a family of dicotyledonous flowering plants placed in the order Fagales, consisting of 3 or 4 genera and approximately 70 species of trees and shrubs native to the Old World tropics , Australia, and the Pacific Islands...
, and
MyricaceaeThe Myricaceae is a small family of dicotyledonous shrubs and small trees in the order Fagales. There are three genera in the family, although some botanists separate many species from Myrica into a fourth genus Morella...
),
RosalesRosales is an order of flowering plants. It is one of the four orders in the nitrogen fixing clade of the fabids and is sister to a clade consisting of Fagales and Cucurbitales. It contains about 7700 species, distributed into about 260 genera. Rosales comprises nine families, the type family...
(
RhamnaceaeRhamnaceae, the Buckthorn family, is a large family of flowering plants, mostly trees, shrubs and some vines.The family contains 50-60 genera and approximately 870-900 species. The Rhamnaceae have a worldwide distribution, but are more common in the subtropical and tropical regions...
,
ElaeagnaceaeElaeagnaceae, the oleaster family, is a plant family of the order Rosales comprising small trees and shrubs, native to temperate regions of the Northern Hemisphere, south into tropical Asia and Australia. The family has 45-50 species in three genera....
and
RosaceaeRosaceae are a medium-sized family of flowering plants, including about 2830 species in 95 genera. The name is derived from the type genus Rosa. Among the largest genera are Alchemilla , Sorbus , Crataegus , Cotoneaster , and Rubus...
). Actinorhizal symbioses account for roughly the same amount of nitrogen fixation as rhizobial symbioses.
Some fungi produce nodular structures known as tuberculate ectomycorrhizae on the roots of their plant hosts.
Suillus tomentosusSuillus tomentosus is a species of mushroom. The common names of the species are Blue-staining Slippery Jack, Poor Man's Slippery Jack, and Woolly-capped Suillus.-Description:...
, for example, produces these structures with its plant host
lodgepole pineLodgepole Pine, Pinus contorta, also known as Shore Pine, is a common tree in western North America. Like all pines, it is evergreen.-Subspecies:...
(
Pinus contorta var.
latifolia). These structures have in turn been shown to host
nitrogen fixingNitrogen fixation is the natural process, either biological or abiotic, by which nitrogen in the atmosphere is converted into ammonia . This process is essential for life because fixed nitrogen is required to biosynthesize the basic building blocks of life, e.g., nucleotides for DNA and RNA and...
bacteriaBacteria are a large domain of prokaryotic microorganisms. Typically a few micrometres in length, bacteria have a wide range of shapes, ranging from spheres to rods and spirals...
which contribute a significant amount of
nitrogenNitrogen is a chemical element that has the symbol N, atomic number of 7 and atomic mass 14.00674 u. Elemental nitrogen is a colorless, odorless, tasteless, and mostly inert diatomic gas at standard conditions, constituting 78.08% by volume of Earth's atmosphere...
and allow the pines to colonize nutrient-poor sites.
