Static electricity refers to the build-up of
electric chargeElectric charge is a physical property of matter that causes it to experience a force when near other electrically charged matter. Electric charge comes in two types, called positive and negative. Two positively charged substances, or objects, experience a mutual repulsive force, as do two...
on the surface of objects. The static charges remain on an object until they either bleed off to
groundIn electrical engineering, ground or earth may be the reference point in an electrical circuit from which other voltages are measured, or a common return path for electric current, or a direct physical connection to the Earth....
or are quickly neutralized by a discharge. Static electricity can be contrasted with
current (or dynamic) electricityElectric current is a flow of electric charge through a medium.This charge is typically carried by moving electrons in a conductor such as wire...
, which can be delivered through wires as a power source. Although charge exchange can happen whenever any two surfaces come into contact and separate, a static charge only remains when at least one of the surfaces has a high resistance to electrical flow (an electrical insulator). The effects of static electricity are familiar to most people because people can feel, hear, and even see the spark as the excess charge is neutralized when brought close to a large
electrical conductorIn physics and electrical engineering, a conductor is a material which contains movable electric charges. In metallic conductors such as copper or aluminum, the movable charged particles are electrons...
(for example, a path to ground), or a region with an excess charge of the opposite polarity (positive or negative). The familiar phenomenon of a static 'shock' is caused by the neutralization of charge.
Causes of static electricity
Materials are made of
atomThe atom is a basic unit of matter that consists of a dense central nucleus surrounded by a cloud of negatively charged electrons. The atomic nucleus contains a mix of positively charged protons and electrically neutral neutrons...
s and
moleculeA molecule is an electrically neutral group of at least two atoms held together by covalent chemical bonds. Molecules are distinguished from ions by their electrical charge...
s that are normally electrically neutral, because they have an equal number of positive charges (
protonThe proton is a subatomic particle with the symbol or and a positive electric charge of 1 elementary charge. One or more protons are present in the nucleus of each atom, along with neutrons. The number of protons in each atom is its atomic number....
s in the
nucleusThe nucleus is the very dense region consisting of protons and neutrons at the center of an atom. It was discovered in 1911, as a result of Ernest Rutherford's interpretation of the famous 1909 Rutherford experiment performed by Hans Geiger and Ernest Marsden, under the direction of Rutherford. The...
) and negative charges (
electronThe electron is a subatomic particle with a negative elementary electric charge. It has no known components or substructure; in other words, it is generally thought to be an elementary particle. An electron has a mass that is approximately 1/1836 that of the proton...
s in "
shellsAn electron shell may be thought of as an orbit followed by electrons around an atom's nucleus. The closest shell to the nucleus is called the "1 shell" , followed by the "2 shell" , then the "3 shell" , and so on further and further from the nucleus. The shell letters K,L,M,.....
" surrounding the nucleus). The phenomenon of static electricity requires a separation of positive and negative charges. When two materials are in contact, electrons may move from one material to the other, which leaves an excess of positive charge on one material, and an equal negative charge on the other. When the materials are separated they retain this charge imbalance.
Contact-induced charge separation
Electrons can be exchanged between materials on contact; materials with weakly bound electrons tend to lose them, while materials with sparsely filled outer shells tend to gain them. This is known as the
triboelectric effectThe triboelectric effect is a type of contact electrification in which certain materials become electrically charged after they come into contact with another different material and are then separated...
and results in one material becoming positively charged and the other negatively charged. The polarity and strength of the charge on a material once they are separated depends on their relative positions in the triboelectric series. The triboelectric effect is the main cause of static electricity as observed in everyday life, and in common high-school science demonstrations involving rubbing different materials together (e.g., fur against an acrylic rod). Contact-induced charge separation causes your hair to stand up and causes "
static clingStatic cling is the tendency for light objects to stick to other objects owing to static electricity. It is common in clothing, but occurs with other items, such as the tendency of dust to be attracted to, and stick to, plastic items....
" (for example, a balloon rubbed against the hair becomes negatively charged; when near a wall, the charged balloon is attracted to positively charged particles in the wall, and can "cling" to it, appearing to be suspended against gravity).
Pressure-induced charge separation
Applied mechanical stress generates a separation of charge in certain types of crystals and
ceramicA ceramic is an inorganic, nonmetallic solid prepared by the action of heat and subsequent cooling. Ceramic materials may have a crystalline or partly crystalline structure, or may be amorphous...
s molecules.
Heat-induced charge separation
Heating generates a separation of charge in the atoms or molecules of certain materials. All pyroelectric materials are also piezoelectric. The atomic or molecular properties of heat and pressure response are closely related.
Charge-induced charge separation
A charged object brought close to an electrically neutral object causes a separation of charge within the neutral object. Charges of the same polarity are repelled and charges of the opposite polarity are attracted. As the force due to the interaction of electric charges falls off rapidly with increasing distance, the effect of the closer (opposite polarity) charges is greater and the two objects feel a force of attraction. The effect is most pronounced when the neutral object is an
electrical conductorIn physics and electrical engineering, a conductor is a material which contains movable electric charges. In metallic conductors such as copper or aluminum, the movable charged particles are electrons...
as the charges are more free to move around. Careful grounding of part of an object with a charge-induced charge separation can permanently add or remove electrons, leaving the object with a global, permanent charge. This process is integral to the workings of the Van de Graaf Generator, a device commonly used to demonstrate the effects of static electricity.
Removal and prevention of static electricity
Removing or preventing a buildup of static charge can be as simple as opening a window or using a
humidifierA humidifier is a household appliance that increases humidity in a single room or in the entire house. There are point-of-use humidifiers, which are commonly used to humidify a single room, and whole-house or furnace humidifiers, which connect to a home's HVAC system to provide humidity to the...
to increase the moisture content of the air, making the atmosphere more conductive. Air ionizers can perform the same task.
Items that are particularly sensitive to static discharge may be treated with the application of an
antistatic agentAn antistatic agent is a compound used for treatment of materials or their surfaces in order to reduce or eliminate buildup of static electricity generally caused by the triboelectric effect. Its role is to make the surface or the material itself slightly conductive, either by being conductive...
, which adds a conducting surface layer that ensures any excess charge is evenly distributed.
Fabric softeners and dryer sheetsFabric softener is used to prevent static cling and make fabric softer. It is available as a liquid, crystals and dryer sheets.- Varieties :...
used in
washing machineA washing machine is a machine designed to wash laundry, such as clothing, towels and sheets...
s and
clothes dryerA clothes dryer or tumble dryer is a household appliance that is used to remove moisture from a load of clothing and other textiles, generally shortly after they are cleaned in a washing machine....
s are an example of an antistatic agent used to prevent and remove
static clingStatic cling is the tendency for light objects to stick to other objects owing to static electricity. It is common in clothing, but occurs with other items, such as the tendency of dust to be attracted to, and stick to, plastic items....
.
Many
semiconductor deviceSemiconductor devices are electronic components that exploit the electronic properties of semiconductor materials, principally silicon, germanium, and gallium arsenide, as well as organic semiconductors. Semiconductor devices have replaced thermionic devices in most applications...
s used in electronics are particularly sensitive to static discharge. Conductive
antistatic bagAn antistatic bag is a bag used for shipping components, which are prone to damage caused by electrostatic discharge.These bags are usually plastic and have a distinctive color . The polyethylene variant may also take the form of foam or bubble wrap, either as sheets or bags...
s are commonly used to protect such components. People who work on circuits that contain these devices often ground themselves with a conductive antistatic strap.
In the industrial settings such as paint or flour plants as well as in hospitals, antistatic safety boots are sometimes used to prevent a buildup of static charge due to contact with the floor. These shoes have soles with good conductivity. Anti-static shoes should not be confused with insulating shoes, which provide exactly the opposite benefit — some protection against serious
electric shockElectric Shock of a body with any source of electricity that causes a sufficient current through the skin, muscles or hair. Typically, the expression is used to denote an unwanted exposure to electricity, hence the effects are considered undesirable....
s from the mains voltage.
Static discharge
The spark associated with static electricity is caused by electrostatic discharge, or simply static discharge, as excess charge is neutralized by a flow of charges from or to the surroundings.
The feeling of an electric shock is caused by the stimulation of nerves as the neutralizing current flows through the human body. The energy stored as static electricity on an object varies depending on the size of the object and its
capacitanceIn electromagnetism and electronics, capacitance is the ability of a capacitor to store energy in an electric field. Capacitance is also a measure of the amount of electric potential energy stored for a given electric potential. A common form of energy storage device is a parallel-plate capacitor...
, the voltage to which it is charged, and the
dielectric constantThe relative permittivity of a material under given conditions reflects the extent to which it concentrates electrostatic lines of flux. In technical terms, it is the ratio of the amount of electrical energy stored in a material by an applied voltage, relative to that stored in a vacuum...
of the surrounding medium. For modelling the effect of static discharge on sensitive electronic devices, a human being is represented as a
capacitorA capacitor is a passive two-terminal electrical component used to store energy in an electric field. The forms of practical capacitors vary widely, but all contain at least two electrical conductors separated by a dielectric ; for example, one common construction consists of metal foils separated...
of 100
picofaradThe farad is the SI unit of capacitance. The unit is named after the English physicist Michael Faraday.- Definition :A farad is the charge in coulombs which a capacitor will accept for the potential across it to change 1 volt. A coulomb is 1 ampere second...
s, charged to a voltage of 4000 to 35000 volts. When touching an object this energy is discharged in less than a microsecond. While the total energy is small, on the order of
millijoulesThe joule ; symbol J) is a derived unit of energy or work in the International System of Units. It is equal to the energy expended in applying a force of one newton through a distance of one metre , or in passing an electric current of one ampere through a resistance of one ohm for one second...
, it can still damage sensitive electronic devices. Larger objects will store more energy, which may be directly hazardous to human contact or which may give a spark that can ignite flammable gas or dust.
Lightning
Lightning is a dramatic natural example of static discharge. While the details are unclear and remain a subject of debate, the initial charge separation is thought to be associated with contact between ice particles within storm clouds. In general, significant charge accumulations can only persist in regions of low electrical conductivity (very few charges free to move in the surroundings), hence the flow of neutralizing charges often results from neutral atoms and molecules in the air being torn apart to form separate positive and negative charges, which travel in opposite directions as an electric current, neutralizing the original accumulation of charge. The static charge in air typically breaks down in this way at around 10,000
voltThe volt is the SI derived unit for electric potential, electric potential difference, and electromotive force. The volt is named in honor of the Italian physicist Alessandro Volta , who invented the voltaic pile, possibly the first chemical battery.- Definition :A single volt is defined as the...
s per centimeter (10 kV/cm) depending on humidity. The discharge superheats the surrounding air causing the bright flash, and produces a shock wave causing the clicking sound. The lightning bolt is simply a scaled up version of the sparks seen in more domestic occurrences of static discharge. The flash occurs because the air in the discharge channel is heated to such a high temperature that it emits light by
incandescenceIncandescence is the emission of light from a hot body as a result of its temperature. The term derives from the Latin verb incandescere, to glow white....
. The clap of
thunderThunder is the sound made by lightning. Depending on the nature of the lightning and distance of the listener, thunder can range from a sharp, loud crack to a long, low rumble . The sudden increase in pressure and temperature from lightning produces rapid expansion of the air surrounding and within...
is the result of the shock wave created as the superheated air expands explosively.
Electronic components
Many
semiconductor deviceSemiconductor devices are electronic components that exploit the electronic properties of semiconductor materials, principally silicon, germanium, and gallium arsenide, as well as organic semiconductors. Semiconductor devices have replaced thermionic devices in most applications...
s used in electronics are very sensitive to the presence of static electricity and can be damaged by a static discharge.
The use of an antistatic strap is mandatory for researchers manipulating nanodevices.
Further precautions can be taken by taking off shoes with thick rubber soles and permanently staying with a metallic ground.
Static build-up in flowing flammable and ignitable materials
Discharge of static electricity can create severe hazards in those industries dealing with flammable substances, where a small electrical spark may ignite explosive mixtures.
The flowing movement of finely powdered substances or low conductivity fluids in pipes or through mechanical agitation can build up static electricity.
Dust clouds of finely powdered substances can become combustible or explosive. When there is a static discharge in a dust or vapor cloud, explosions have occurred. Among the major industrial incidents that have occurred are: a grain silo in southwest France, a paint plant in Thailand, a factory making
fiberglassGlass fiber is a material consisting of numerous extremely fine fibers of glass.Glassmakers throughout history have experimented with glass fibers, but mass manufacture of glass fiber was only made possible with the invention of finer machine tooling...
moldings in Canada, a storage tank explosion in
Glenpool, Oklahoma in 2003, and a portable tank filling operation and a tank farm in Des Moines, Iowa and
Valley Center, KansasValley Center is a city in Sedgwick County, Kansas, United States. As of the 2010 census, the city population was 6,822.-History:Valley Center was incorporated on September 29, 1885, and was named for its location on the Arkansas River....
in 2007.
The ability of a fluid to retain an electrostatic charge depends on its electrical conductivity. When low conductivity fluids flow through pipelines or are mechanically agitated, contact-induced charge separation called
flow electrification occurs.
Fluids that have low electrical conductivity (below 50
picosiemensThe siemens is the SI derived unit of electric conductance and electric admittance. Conductance and admittance are the reciprocals of resistance and impedance respectively, hence one siemens is equal to the reciprocal of one ohm, and is sometimes referred to as the mho. In English, the term...
per meter), are called accumulators. Fluids having conductivities above 50 pS/m are called non-accumulators. In non-accumulators, charges recombine as fast as they are separated and hence electrostatic charge accumulation is not significant. In the petrochemical industry, 50 pS/m is the recommended minimum value of electrical conductivity for adequate removal of charge from a fluid.
Kerosines may have conductivity ranging from less than 1 picosiemens per meter to 20 pS/m. For comparison, deionized water has a conductivity of about
10,000,000 pS/m or 10 µS/m.
Transformer oilTransformer oil or insulating oil is usually a highly-refined mineral oil that is stable at high temperatures and has excellent electrical insulating properties. It is used in oil-filled transformers, some types of high voltage capacitors, fluorescent lamp ballasts, and some types of high voltage...
is part of the electrical insulation system of large power
transformerA transformer is a device that transfers electrical energy from one circuit to another through inductively coupled conductors—the transformer's coils. A varying current in the first or primary winding creates a varying magnetic flux in the transformer's core and thus a varying magnetic field...
s and other electrical apparatus. Re-filling of large apparatus requires precautions against electrostatic charging of the fluid, which may damage sensitive transformer insulation.
An important concept for insulating fluids is the static relaxation time. This is similar to the time constant τ (tau) within an
RC circuitA resistor–capacitor circuit ', or RC filter or RC network, is an electric circuit composed of resistors and capacitors driven by a voltage or current source...
. For insulating materials, it is the ratio of the static
dielectric constantThe relative permittivity of a material under given conditions reflects the extent to which it concentrates electrostatic lines of flux. In technical terms, it is the ratio of the amount of electrical energy stored in a material by an applied voltage, relative to that stored in a vacuum...
divided by the electrical conductivity of the material. For hydrocarbon fluids, this is sometimes approximated by dividing the number 18 by the electrical conductivity of the fluid. Thus a fluid that has an electrical conductivity of 1 pS/m has an estimated relaxation time of about 18 seconds. The excess charge in a fluid dissipates almost completely after four to five times the relaxation time, or 90 seconds for the fluid in the above example.
Charge generation increases at higher fluid velocities and larger pipe diameters, becoming quite significant in pipes 8 inches (200 mm) or larger. Static charge generation in these systems is best controlled by limiting fluid velocity. The British standard BS PD CLC/TR 50404:2003 (formerly BS-5958-Part 2) Code of Practice for Control of Undesirable Static Electricity prescribes pipe flow velocity limits. Because water content has a large impact on the fluids dielectric constant, the recommended velocity for hydrocarbon fluids containing water should be limited to 1 meter per second.
Bonding and earthing are the usual ways charge buildup can be prevented. For fluids with electrical conductivity below 10 pS/m, bonding and earthing are not adequate for charge dissipation, and anti-static additives may be required.
Fueling operations
The flowing movement of flammable liquids like gasoline inside a pipe can build up static electricity. Non-polar liquids such as
paraffinIn chemistry, paraffin is a term that can be used synonymously with "alkane", indicating hydrocarbons with the general formula CnH2n+2. Paraffin wax refers to a mixture of alkanes that falls within the 20 ≤ n ≤ 40 range; they are found in the solid state at room temperature and begin to enter the...
,
gasolineGasoline , or petrol , is a toxic, translucent, petroleum-derived liquid that is primarily used as a fuel in internal combustion engines. It consists mostly of organic compounds obtained by the fractional distillation of petroleum, enhanced with a variety of additives. Some gasolines also contain...
,
tolueneToluene, formerly known as toluol, is a clear, water-insoluble liquid with the typical smell of paint thinners. It is a mono-substituted benzene derivative, i.e., one in which a single hydrogen atom from the benzene molecule has been replaced by a univalent group, in this case CH3.It is an aromatic...
,
xyleneXylene encompasses three isomers of dimethylbenzene. The isomers are distinguished by the designations ortho- , meta- , and para- , which specify to which carbon atoms the two methyl groups are attached...
, diesel,
keroseneKerosene, sometimes spelled kerosine in scientific and industrial usage, also known as paraffin or paraffin oil in the United Kingdom, Hong Kong, Ireland and South Africa, is a combustible hydrocarbon liquid. The name is derived from Greek keros...
and
light crude oilLight crude oil is liquid petroleum that has a low density and flows freely at room temperature. It has a low viscosity, low specific gravity and high API gravity due to the presence of a high proportion of light hydrocarbon fractions. It generally has a low wax content...
s exhibit significant ability for charge accumulation and charge retention during high velocity flow. Static electricity can discharge into a
fuelFuel is any material that stores energy that can later be extracted to perform mechanical work in a controlled manner. Most fuels used by humans undergo combustion, a redox reaction in which a combustible substance releases energy after it ignites and reacts with the oxygen in the air...
vapor.
When the electrostatic discharge energy is high enough, it can ignite a fuel vapor and air mixture. Different fuels have different flammable limits and require different levels of electrostatic discharge energy to ignite.
Electrostatic discharge while fueling with gasoline is a present danger at gas stations. Fires have also been started at airports while refueling
aircraftAn aircraft is a vehicle that is able to fly by gaining support from the air, or, in general, the atmosphere of a planet. An aircraft counters the force of gravity by using either static lift or by using the dynamic lift of an airfoil, or in a few cases the downward thrust from jet engines.Although...
with kerosene. New grounding technologies, the use of conducting materials, and the addition of anti-static additives help to prevent or safely dissipate the build up of static electricity.
The flowing movement of gases in pipes alone creates little, if any, static electricity. It is envisaged that a charge generation mechanism only occurs when solid particles or liquid droplets are carried in the gas stream.
Static discharge in space exploration
Due to the extremely low humidity in extraterrestrial environments, very large static charges can accumulate, causing a major hazard for the complex electronics used in space exploration vehicles. Static electricity is thought to be a particular hazard for astronauts on
planned missionsThe Vision for Space Exploration is the United States space policy which was announced on January 14, 2004 by President George W. Bush. It is seen as a response to the Space Shuttle Columbia disaster, the state of human spaceflight at NASA, and a way to regain public enthusiasm for space...
to
the MoonThe Moon is Earth's only known natural satellite,There are a number of near-Earth asteroids including 3753 Cruithne that are co-orbital with Earth: their orbits bring them close to Earth for periods of time but then alter in the long term . These are quasi-satellites and not true moons. For more...
and
MarsMars is the fourth planet from the Sun in the Solar System. The planet is named after the Roman god of war, Mars. It is often described as the "Red Planet", as the iron oxide prevalent on its surface gives it a reddish appearance...
. Walking over the extremely dry terrain could cause them to accumulate a significant amount of charge; reaching out to open the airlock on their return could cause a large static discharge, potentially damaging sensitive electronics.
Ozone cracking
A static discharge in the presence of air or oxygen can create
ozoneOzone , or trioxygen, is a triatomic molecule, consisting of three oxygen atoms. It is an allotrope of oxygen that is much less stable than the diatomic allotrope...
. Ozone can attack rubber parts. Many
elastomerAn elastomer is a polymer with the property of viscoelasticity , generally having notably low Young's modulus and high yield strain compared with other materials. The term, which is derived from elastic polymer, is often used interchangeably with the term rubber, although the latter is preferred...
s are sensitive to
ozone crackingCracks can be formed in many different elastomers by ozone attack, and the characteristic form of attack of vulnerable rubbers is known as ozone cracking...
. Exposure to ozone creates deep penetrative cracks in critical components like
gasketthumb|sright|250px|Some seals and gaskets1. [[o-ring]]2. fiber [[Washer |washer]]3. paper gaskets4. [[cylinder head]] [[head gasket|gasket]]...
s and
O-ringAn O-ring, also known as a packing, or a toric joint, is a mechanical gasket in the shape of a torus; it is a loop of elastomer with a disc-shaped cross-section, designed to be seated in a groove and compressed during assembly between two or more parts, creating a seal at the interface.The O-ring...
s.
Fuel lineA fuel line is a hose used to bring fuel from one point in a vehicle to another or from a storage tank to a vehicle. It is commonly made of reinforced rubber to prevent splitting and kinking....
s are also susceptible to the problem unless preventative action is taken. Preventative measures include adding anti-ozonants to the rubber mix, or using an ozone-resistant elastomer. Fires from cracked fuel lines have been a problem on vehicles, especially in the engine compartments where ozone can be produced by electrical equipment.
Energies involved
The energy released in a static electricity discharge may vary over a wide range. The energy in joules can be calculated from the
capacitanceIn electromagnetism and electronics, capacitance is the ability of a capacitor to store energy in an electric field. Capacitance is also a measure of the amount of electric potential energy stored for a given electric potential. A common form of energy storage device is a parallel-plate capacitor...
(
C) of the object and the static potential
V in volts (V) by the formula
E = ½
CV2. One experimenter estimates the capacitance of the human body as high as 400 picofarads, and a charge of 50,000 volts, discharged e.g. during touching a charged car, creating a spark with energy of 500 millijoules. Another estimate is 100–300 pF and 20,000 volts, producing a maximum energy of 60 mJ. IEC 479-2:1987 states that a discharge with energy greater than 5000 mJ is a direct serious risk to human health. IEC 60065 states that consumer products cannot discharge more than 350 mJ into a person.
The maximum potential is limited to about 35–40 kV, due to
corona dischargeIn electricity, a corona discharge is an electrical discharge brought on by the ionization of a fluid surrounding a conductor that is electrically energized...
dissipating the charge at higher potentials. Potentials below 300 volts are not typically detectable by humans. Maximum potential commonly achieved on human body range between 1 and 10 kV, though in optimal conditions as high as 20–25 kV can be reached. Low relative humidity increases the charge buildup; walking 20 feet (6.1 m) on vinyl floor at 15% relative humidity causes buildup of voltage up to 12 kilovolts, while at 80% humidity the voltage is only 1.5 kV.
As little as 0.2 millijoules may present an ignition hazard; such low spark energy is often below the threshold of human visual and auditory perception.
Typical ignition energies are:
- 0.017 mJ for hydrogen
Hydrogen is the chemical element with atomic number 1. It is represented by the symbol H. With an average atomic weight of , hydrogen is the lightest and most abundant chemical element, constituting roughly 75% of the Universe's chemical elemental mass. Stars in the main sequence are mainly...
- 0.2-2 mJ for hydrocarbon
In organic chemistry, a hydrocarbon is an organic compound consisting entirely of hydrogen and carbon. Hydrocarbons from which one hydrogen atom has been removed are functional groups, called hydrocarbyls....
vapors
- 1–50 mJ for fine flammable dust
- 40–1000 mJ for coarse flammable dust
The energy needed to damage most electronic devices is between 2 and 1000 nanojoules.
A relatively small energy, often as little as 0.2–2 millijoules, is needed to ignite a flammable mixture of a fuel and air. For the common industrial hydrocarbon gases and solvents, the
minimum ignition energyMinimum ignition energy is the minimum amount of energy required to ignite a combustible vapor, gas or dust cloud, for example due to an electrostatic discharge. MIE is measured in joules ....
required for ignition of vapor-air mixture is lowest for the vapor concentration roughly in the middle between the lower explosive limit and the upper explosive limit, and rapidly increases as the concentration deviates from this optimum to either side. Aerosols of flammable liquids may be ignited well below their
flash pointThe flash point of a volatile material is the lowest temperature at which it can vaporize to form an ignitable mixture in air. Measuring a flash point requires an ignition source...
. Generally, liquid aerosols with particle sizes below 10 micrometers behave like vapors, particle sizes above 40 micrometers behave more like flammable dusts. Typical minimum flammable concentrations of aerosols lay between 15 and 50 g/m
3. Similarly, presence of foam on the surface of a flammable liquid significantly increases ignitability. Aerosol of flammable dust can be ignited as well, resulting in a
dust explosionA dust explosion is the fast combustion of dust particles suspended in the air in an enclosed location. Coal dust explosions are a frequent hazard in underground coal mines, but dust explosions can occur where any powdered combustible material is present in an enclosed atmosphere.- Conditions for...
; the lower explosive limit usually lies between 50 and 1000 g/m
3; finer dusts tend to be more explosive and requiring less spark energy to set off. Simultaneous presence of flammable vapors and flammable dust can significantly decrease the ignition energy; a mere 1 vol.% of propane in air can reduce the required ignition energy of dust by 100 times. Higher than normal oxygen content in atmosphere also significantly lowers the ignition energy.
There are five types of electrical discharges:
- Spark, responsible for the majority of industrial fires and explosions where static electricity is involved. Sparks occur between objects at different electric potentials. Good grounding of all parts of the equipment and precautions against charge buildups on equipment and personnel are used as prevention measures.
- Brush discharge
A brush discharge is a type of corona discharge that takes place between two electrodes embedded in a nonconducting medium and is characterized by nonsparking, faintly luciferous furcations composed of ionized particles....
occurs from a nonconductive charged surface or highly charged nonconductive liquids. The energy is limited to roughly 4 millijoules. To be hazardous, the voltage involved must be above about 20 kilovolts, the surface polarity is negative, flammable atmosphere is present at the point of discharge, and the discharge energy is sufficient for ignition. Due to maximum charge density on surface, an area of at least 100 cm2 has to be involved. Not observed as a hazard for dust clouds.
- Propagating brush discharge is high in energy and dangerous. Occurs when an insulating surface of up to 8 mm thick (e.g. a teflon or glass lining of a grounded metal pipe or a reactor) is subjected to a large charge buildup between the opposite surfaces, acting as a large-area capacitor.
- Cone discharge, also called bulking brush discharge, occurs over surfaces of charged powders with resistivity above 1010 ohms, or also deep through the powder mass. Cone discharges aren't usually observed in dust volumes below 1 m3. The energy involved depends on the grain size of the powder and the charge magnitude, and can reach up to 20 mJ. Larger dust volumes produce higher energies.
- Corona discharge
In electricity, a corona discharge is an electrical discharge brought on by the ionization of a fluid surrounding a conductor that is electrically energized...
, considered non-hazardous
Applications of static electricity
Static electricity is commonly used in
xerographyXerography is a dry photocopying technique invented by Chester Carlson in 1938, for which he was awarded on October 6, 1942. Carlson originally called his invention electrophotography...
,
air filterA particulate air filter is a device composed of fibrous materials which removes solid particulates such as dust, pollen, mold, and bacteria from the air. A chemical air filter consists of an absorbent or catalyst for the removal of airborne molecular contaminants such as volatile organic compounds...
s (particularly
electrostatic precipitatorAn electrostatic precipitator , or electrostatic air cleaner is a particulate collection device that removes particles from a flowing gas using the force of an induced electrostatic charge...
s), automotive paints, photocopiers, paint sprayers, theaters, flooring in operating theaters, powder testing, printers, static bonding and aircraft refueling.
Simple static electricity experiments
- Note: a humid atmosphere provides a conducting path for the rapid neutralization of static charge; hence the following examples work best in dry conditions.
Static electricity is notable as a physical phenomenon that can be demonstrated using simple experiments that can convey genuine understanding of the physics involved.
Charged adhesive tape
A simple and illuminating example of the effects of static electricity can be observed using
adhesive tapePressure-sensitive tape, known also in various countries as PSA tape, adhesive tape, self-stick tape, sticky tape, or just tape, is an adhesive tape that will stick with application pressure, without the need for solvent, heat, or water for activation...
, charged by peeling. For example,
Scotch tapeScotch Tape is a brand name used for certain pressure sensitive tapes manufactured by 3M as part of the company's Scotch brand.- History :The precursor to the current tapes was developed in the 1930s in Minneapolis, Minnesota by Richard Drew to seal a then-new transparent material known as...
is on the negative side of the triboelectric series, hence tends to gain electrons and acquire negative charge.
If a length of tape adhered to a smooth surface is rapidly peeled off, the tape acquires an excess negative charge (generally
polypropylenePolypropylene , also known as polypropene, is a thermoplastic polymer used in a wide variety of applications including packaging, textiles , stationery, plastic parts and reusable containers of various types, laboratory equipment, loudspeakers, automotive components, and polymer banknotes...
with an acrylic adhesive.) Do this with two lengths of tape and they repel each other, which demonstrates that
like charges repel. Each individual length of tape is at least slightly attracted to almost any object, as the presence of the excess negative charge induces a charge separation in nearby objects. Negative charges are pushed farther away, while positive charges are attracted, and the strength of the attractive and repulsive
forceIn physics, a force is any influence that causes an object to undergo a change in speed, a change in direction, or a change in shape. In other words, a force is that which can cause an object with mass to change its velocity , i.e., to accelerate, or which can cause a flexible object to deform...
s falls off
quite rapidly with distanceIn physics, an inverse-square law is any physical law stating that a specified physical quantity or strength is inversely proportional to the square of the distance from the source of that physical quantity....
. This effect is most pronounced in materials such as
metalA metal , is an element, compound, or alloy that is a good conductor of both electricity and heat. Metals are usually malleable and shiny, that is they reflect most of incident light...
s, that
conduct electricityIn physics and electrical engineering, a conductor is a material which contains movable electric charges. In metallic conductors such as copper or aluminum, the movable charged particles are electrons...
, as the negative charges are free to move within the material.
Finally, try attaching two lengths of tape together, exhaling on them along the entire length to neutralize the charge, then rapidly pulling them apart. There will be some imbalance in the distribution of negative charge between the two pieces such that one is
more positive and the other
more negative; you should now find that the two lengths of tape attract each other, demonstrating the fact that
opposite charges attract. Attaching the adhesive side of one length of tape to the non-adhesive side of the other reduces the chance of tearing and increases the charge imbalance, and hence the strength of the attractive force.
Static electricity in fiction
In the 1957
Atlas ShruggedAtlas Shrugged is a novel by Ayn Rand, first published in 1957 in the United States. Rand's fourth and last novel, it was also her longest, and the one she considered to be her magnum opus in the realm of fiction writing...
, a novel by
Ayn RandAyn Rand was a Russian-American novelist, philosopher, playwright, and screenwriter. She is known for her two best-selling novels The Fountainhead and Atlas Shrugged and for developing a philosophical system she called Objectivism....
, the principal character
John GaltJohn Galt was a Scottish novelist, entrepreneur, and political and social commenter. Because he was the first novelist to deal with issues of the industrial revolution, he has been called the first political novelist in the English language.-Life:Born in Irvine, North Ayrshire, Scotland, Galt was...
invents a perpetually running motor that transforms atmospheric static electricity into kinetic electricity.
In the 1959
Hugo AwardThe Hugo Awards are given annually for the best science fiction or fantasy works and achievements of the previous year. The award is named after Hugo Gernsback, the founder of the pioneering science fiction magazine Amazing Stories, and was officially named the Science Fiction Achievement Awards...
winning "
A Case of ConscienceA Case of Conscience is a science fiction novel by James Blish, first published in 1958. It is the story of a Jesuit who investigates an alien race that has no religion; they are completely without any concept of God, an afterlife, or the idea of sin; and the species evolves through several forms...
" by
James BlishJames Benjamin Blish was an American author of fantasy and science fiction. Blish also wrote literary criticism of science fiction using the pen-name William Atheling, Jr.-Biography:...
, an extremely ancient alien race on a planet around a distant star, developed a jetplane whose electrical wiring operated purely on static electricity.
In the British science-fiction television series, "
Doctor WhoDoctor Who is a British science fiction television programme produced by the BBC. The programme depicts the adventures of a time-travelling humanoid alien known as the Doctor who explores the universe in a sentient time machine called the TARDIS that flies through time and space, whose exterior...
", an alien creature encased in metal, called a
DalekThe Daleks are a fictional extraterrestrial race of mutants from the British science fiction television series Doctor Who. Within the series, Daleks are cyborgs from the planet Skaro, created by the scientist Davros during the final years of a thousand-year war against the Thals...
, is powered by static electricity.
See also
- Electrical charge
- Electrostatics
Electrostatics is the branch of physics that deals with the phenomena and properties of stationary or slow-moving electric charges....
- Electrostatic generator
An electrostatic generator, or electrostatic machine, is a mechanical device that produces static electricity, or electricity at high voltage and low continuous current...
- Electrostatic discharge
Electrostatic discharge is a serious issue in solid state electronics, such as integrated circuits. Integrated circuits are made from semiconductor materials such as silicon and insulating materials such as silicon dioxide...
- Triboelectrification
- Wimshurst machine
The Wimshurst influence machine is an electrostatic generator, a machine for generating high voltages developed between 1880 and 1883 by British inventor James Wimshurst ....
- Van de Graaff generator
A Van de Graaff generator is an electrostatic generator which uses a moving belt to accumulate very high voltages on a hollow metal globe on the top of the stand. It was invented in 1929 by American physicist Robert J. Van de Graaff. The potential differences achieved in modern Van de Graaff...
